x |
 |
Service: ultrasonic cleaning of empty carburetor housing | 0039002 |
13110039002 |
R25 |
1 |
€21,18
|
|
|
|
x |
|
Used part: Bing carburetor 1/22/44, overhauled (on request only) ►see details |
|
|
R25/2 |
1 |
Not available |
|
|
|
x |
|
Used part: Carburetor Bing 1/24/42 for R25/3 - overhauled |
|
|
R25/3 |
1 |
Not available |
|
|
|
x |
 |
Gasket set carburetor BING R25 - R25/3 ►see details | 0039006 |
13110039006DS |
R25, R25/2, R25/3 |
1 |
€3,09
|
|
|
|
1 |
 |
Air filter - reproduction | 0043005.AM |
13720043005 |
R25/3 |
1 |
€80,83
|
|
|
|
2 |
 |
Tickler for BING carburetor, plastic cap, R25 - R27 | 0039161 |
13110039161 |
|
1 |
€9,56
|
|
|
|
3 |
 |
Split pin for tickler, Bing 49-030 | 0039165 |
13110039165 |
|
1 |
€0,61
|
|
|
|
4 |
 |
Tickler spring Bing 60-048 Ø = 4.5, L = 35 mm | 0039164 |
13110039164 |
|
1 |
€0,54
|
|
|
|
5 |
 |
Hex screw M5 x 13 mm for float chamber cover, Bing 40-528 | 0039156 |
13110039156 |
|
2 |
€7,32
|
|
|
|
6 |
 |
Spring washer for carburetor, Bing 61-680 | 0039193 |
13110039193 |
R25/3 |
1 |
€0,35
|
|
|
|
7 |
|
Cover with tickler Bing 32-991 |
|
|
|
1 |
Not available |
|
|
|
8 |
|
Gasket float chamber Bing 165-540 |
|
|
|
1 |
Not available |
|
|
|
9 |
 |
Float 11 gram, Bing 35-073 | 0039186 |
13110039186 |
|
1 |
€63,59
|
|
|
|
10 |
 |
Carburetor float needle, Bing 47-960 | 0039188 |
13110039188 |
|
1 |
€9,74
|
|
|
|
11 |
 |
Cable adjusting screw on carburetor, 25 mm (Bing 50-050) | 0039178 |
13110039178 |
|
1 |
€3,51
|
|
|
|
12 |
 |
Carburetor slide cover | 0039109 |
13110039109 |
R25, R25/2 |
1 |
€47,31
|
|
|
|
|
 |
Carburetor slide cover, with pipe bend | 0039108 |
13110039108 |
R25/3 |
1 |
€59,59
|
|
|
|
13 |
 |
Cover ring carburetor Bing 21-500 (M34) | 0039115 |
13110039115 |
|
1 |
€25,29
|
|
|
|
14 |
 |
Slide valve spring Bing 60-110, L = 65 mm, D = 6.1 mm | 0039169 |
13110039169 |
|
1 |
€1,19
|
|
|
|
15 |
 |
Needle Bing 46-921, old model | 0039172 |
13110039172 |
R25, R25/2 |
1 |
€13,25
|
|
|
|
|
 |
Needle Bing 46-222 | 0039173 |
13110039173 |
R25/3 |
1 |
€19,42
|
|
|
|
16 |
 |
Retaining clip, early model Bing 61-400 | 0039175 |
13110039175 |
R25, R25/2 |
1 |
€2,72
|
|
|
|
|
 |
Retaining clip, Bing 61-375 | 0039176 |
13110039176 |
R25/3 |
1 |
€6,72
|
|
|
|
17 |
 |
Carburetor slide 27 mm Bing 22-460 | 0039119 |
13110039119 |
R25, R25/2 |
1 |
€38,60
|
|
|
|
|
 |
Carburetor slide 27 mm Bing 22-470 | 0039120 |
13110039120 |
R25/3 |
1 |
€37,69
|
|
|
|
18 |
|
Used part: Carburetor Bing 1/24/42 for R25/3 - overhauled |
|
|
R25/3 |
1 |
Not available |
|
|
|
|
|
Used part: Bing carburetor 1/22/44, overhauled (on request only) ►see details |
|
|
R25/2 |
1 |
Not available |
|
|
|
18 |
|
Carburetor Blitz for R25/3 |
|
|
R25/3 |
1 |
Not available |
|
|
|
19 |
 |
Flange gasket carburetor & cyl. head R25 - R25/3, R51/3 - R67/3, R50 - R60/2 | 0042146 |
13110042146 |
|
1 |
€8,53
|
|
|
|
20 |
 |
Carburetor idle jet , Bing 44-031 | 0039137 |
13110039137 |
R25 |
1 |
€9,14
|
|
|
|
|
|
Carburetor idle jet , Bing 44-031 | 0039137 |
13110039137 |
R25/2, R25/3 |
1 |
€9,14
|
|
|
|
21 |
 |
Gasket ring Bing 65-102 | 0042126 |
13110042126 |
|
1 |
€0,61
|
|
|
|
22 |
 |
Screw plug M7 x 0.75 Bing 140-706 | 0039196 |
13110039196 |
M7x0.75 |
1 |
€3,15
|
|
|
|
23 |
 |
Gasket ring for carburetor hose connection | 0042120 |
13110042120 |
|
1 |
€0,57
|
|
|
|
24 |
 |
Fuel hose connection | 0039191 |
13110039191 |
|
1 |
€43,62
|
|
|
|
25 |
 |
Gasket ring carburetor | 0042122 |
13110042122 |
|
1 |
€0,58
|
|
|
|
26 |
 |
Screw plug Bing 50-225 | 0039192 |
13110039192 |
|
1 |
€11,31
|
|
|
|
27 |
 |
Jam nut for idle mix screw and cable guide, Bing 42-702 | 0039184 |
13110039184 |
|
1 |
€0,92
|
|
|
|
28 |
 |
Idle mix screw cap, Bing 57-560 | 0039185 |
13110039185 |
|
1 |
€3,35
|
|
|
|
29 |
 |
Idle mix screw sleeve, Bing 50-520 | 0039183 |
13110039183 |
|
1 |
€4,78
|
|
|
|
30 |
 |
Idle mix screw, Bing 50-920 | 0039181 |
13110039181 |
|
1 |
€11,92
|
|
|
|
x |
 |
Idle jet R25, R51/2 | 0039140 |
13110039140 |
R25 |
1 |
€25,77
|
|
|
|
31 |
 |
Gasket ring Ø13 mm Bing | 0042134 |
13110042134 |
|
1 |
€0,85
|
|
|
|
32 |
 |
Screw cap (thread Ø 13 mm x 0.8), Bing 50-200 | 0039198 |
13110039198 |
|
1 |
€6,95
|
|
|
|
33 |
 |
Needle jet 1208 Bing 45-251 (Ø 2.64 mm) | 0039123 |
13110039123 |
R25, R25/3 |
1 |
€20,15
|
|
|
|
|
 |
Needle jet 1708 Bing 45-251 | 0039121 |
13110039121 |
R25/2 |
1 |
€21,05
|
|
|
|
|
 |
Alu-bronze threaded bushing M7 / M6 x 0.75 for needle jet and slide stop screw ►see details | 0039123.6 |
13110039123.6 |
|
1 |
€34,55
|
|
|
|
33a |
 |
Threaded insert Bing 50-390 | 0039194 |
13110039194 |
R25, R25/2 |
1 |
€11,19
|
|
|
|
34 |
 |
Carburetor main jet 100, Bing 44-051 (D~0.93 mm) | 0039143 |
13110039143 |
R25 |
1 |
€9,20
|
|
|
|
|
 |
Carburetor main jet 110, Bing 44-051 (D~1.03 mm) | 0039144 |
13110039144 |
R25/2 |
1 |
€8,62
|
|
|
|
|
 |
Carburetor main jet 145, Bing 44-051 (D~1.3 mm) | 0039145 |
13110039145 |
R25/3 |
1 |
€9,20
|
|
|
|
35 |
 |
Gasket ring for main jet cover screw | 0042130 |
13110042130 |
|
1 |
€0,35
|
|
|
|
36 |
 |
Screw cap main jet M15 x 1, Bing 50-250 | 0039197 |
13110039197 |
R25, R25/2 |
1 |
€10,95
|
|
|
|
|
 |
Screw cap Bing 50-240, M15 x 1 (short model) | 0039199 |
13110039199 |
R25/3 |
1 |
€7,56
|
|
|
|
37 |
 |
Spring 13 mm for stop screw, Bing 60-280 (bare steel) | 0039170 |
13110039170 |
|
1 |
€2,18
|
|
|
|
38 |
 |
Stop screw for carburetor slide, M6 x 0.75, L = 32 mm | 0039151 |
13110039151 |
R25, R25/2 |
1 |
€8,65
|
|
|
|
|
 |
Stop screw for carburetor slide Bing 50-085, M6 x 0.75, L = 37 mm | 0039527 |
13110039527 |
R25/3 |
1 |
€8,13
|
|
|
|
|
|
Alu-bronze threaded bushing M7 / M6 x 0.75 for needle jet and slide stop screw ►see details | 0039123.6 |
13110039123.6 |
|
1 |
€34,55
|
|
|
|
39 |
 |
Carburetor / air tube clamp spring, original form - SSt | 0043103 |
13110043103 |
R25/3 |
2 |
€7,80
|
|
|
|
40 |
 |
Rubber sleeve carburetor R25/3 | 0043108 |
11610043108 |
|
1 |
€16,03
|
|
|
|
42 |
 |
Hex nut for cable adjusting screw Bing 42-605 | 0039182 |
13110039182 |
|
1 |
€1,03
|
|
|
|
c |
|
Gasket set carburetor BING R25 - R25/3 ►see details | 0039006 |
13110039006DS |
R25/3 |
1 |
€3,09
|
|
|
|
d |
 |
Carburetor Bing 1/24/42 for R25/3 - original - New Old Stock | 0039006.NOS |
13110039006.NOS |
R25/3 |
1 |
€961,95
|
|
|
