x |
 |
Gasket set carburetor - all 2 cyl. | 5590039 |
13115590039 |
all |
2 |
€4,78
|
|
|
|
1 |
 |
Cover ring, M38 x 1 - 13 mm height, Bing 21-542 | 0039216 |
13110039216 |
R50/2, R50S, R60/2, R69, R69S |
2 |
€37,75
|
|
|
|
|
 |
Cover ring, M34 x 1 - 13 mm height, Bing 21-502 | 0039215 |
13110039215 |
(R50, R60) |
2 |
€21,18
|
|
|
|
|
 |
Cover ring, M34 x 1 - 17.5 mm height, Bing 21-505 | 0039217 |
13110039217 |
R50, R50/2, R60, R60/2 |
2 |
€22,63
|
|
|
|
2 |
 |
Rubber O-ring Bing 65-730 | 0042149 |
13110042149 |
|
2 |
€3,05
|
|
|
|
3 |
 |
Carburetor slide cover plate, LH side, Bing 30-320, after-market | 0039111 |
13110039111 |
R50, R60 (R50/2, R60/2) |
1 |
€82,28
|
|
|
|
|
 |
Carburetor slide cover plate, RH side, Bing 30-322, after-market | 0039112 |
13110039112 |
R50, R60 (R50/2, R60/2) |
1 |
€82,28
|
|
|
|
|
 |
Cover for carburetor L/R (for M38 cover ring) ►see details | 0039219.3 |
13110039219.3 |
R50/2, R50S, R60/2, R69, R69S |
1 |
€51,73
|
|
|
|
|
|
Cover for carburetor L/R (for M38 cover ring) ►see details | 0039219.3 |
13110039219.3 |
R50/2, R50S, R60/2, R69, R69S |
2 |
€51,73
|
|
|
|
|
 |
Bend for carburetor cover Bing 55-205-01 | 0039219.R |
13110039219.R |
R50/2, R50S, R60/2, R69, R69S |
2 |
€5,87
|
|
|
|
4 |
 |
Rubber boot for throttle cable at carburetor | 0042111 |
13110042111 |
|
2 |
€2,53
|
|
|
|
5 |
 |
Cable adjusting screw on carburetor, 25 mm (Bing 50-050) | 0039178 |
13110039178 |
|
2 |
€3,51
|
|
|
|
6 |
 |
Spring for carburetor slide R68, R50S - R69S (Bing 60-190) Ø=8mm, L=70 mm | 0039168 |
13110039168 |
R50S, R69, R69S |
2 |
€1,65
|
|
|
|
|
 |
Slide valve spring Bing 60-110, L = 65 mm, D = 6.1 mm | 0039169 |
13110039169 |
R50, R50/2, R60, R60/2 |
2 |
€1,19
|
|
|
|
7 |
 |
Carburetor slide needle no. 4 Bing 46-934 | 0039272 |
13110039272 |
R50S, R69, R69S |
2 |
€9,38
|
|
|
|
|
 |
Carburetor slide needle - Bing 46-255 | 0039274 |
13110039274 |
R50, R50/2, R60, R60/2 |
2 |
€19,32
|
|
|
|
|
 |
Carburetor slide needle - Bing 46-254 | 1250755 |
13111250755 |
R69S |
2 |
€19,30
|
|
|
|
8 |
 |
Retaining clip, early model Bing 61-400 | 0039175 |
13110039175 |
i.c.w. Bing 46-934 |
2 |
€2,72
|
|
|
|
|
 |
Retaining clip, Bing 61-375 | 0039176 |
13110039176 |
i.c.w. Bing 46-254 & 46-255 |
2 |
€6,72
|
|
|
|
10 |
 |
Carburetor slide Ø 29.4 mm Bing 22-542 ►see details | 0039116 |
13110039116 |
R50, R50/2, R60, R60/2, R69S |
2 |
€59,41
|
|
|
|
10 |
 |
Carburetor slide Ø 30.0 mm (+0.5 mm oversize) | 0039116.1 |
13110039116.1 |
R50, R50/2, R60, R60/2, R69S |
2 |
€56,08
|
|
|
|
10 |
 |
Carburetor slide 27 mm Bing 22-470 | 0039120 |
13110039120 |
R50, R50/2, R60, R60/2 |
2 |
€37,69
|
|
|
|
10 |
 |
Carburetor slide 27 mm + 0.15 mm Bing 22-470 | 0039120.1 |
13110039120.1 |
R50, R50/2, R60, R60/2 |
1 |
€38,48
|
|
|
|
12 |
 |
Flange gasket carburetor & cyl. head R25 - R25/3, R51/3 - R67/3, R50 - R60/2 | 0042146 |
13110042146 |
R50, R50/2, R60, R60/2 |
2 |
€8,53
|
|
|
|
|
 |
Flange gasket carburetor & cyl. head R68, R50S, R69, R69S | 0042147 |
13110042147 |
R50S, R69, R69S |
2 |
€9,56
|
|
|
|
14 |
 |
Jam nut for idle mix screw and cable guide, Bing 42-702 | 0039184 |
13110039184 |
|
2 |
€0,92
|
|
|
|
15 |
 |
Idle mix screw, Bing 50-920 | 0039181 |
13110039181 |
|
2 |
€11,92
|
|
|
|
15 |
 |
Alu-bronze threaded bushing M8 / M7 x 0.75 x 10 mm for idle mix screw (only i.c.w. new idle mix screw!) ►see details | 0039181.6 |
13110039181.6 |
|
1 |
€32,43
|
|
|
|
16 |
 |
Idle mix screw cap, Bing 57-560 | 0039185 |
13110039185 |
|
2 |
€3,35
|
|
|
|
17 |
 |
Idle mix screw sleeve, Bing 50-520 | 0039183 |
13110039183 |
|
2 |
€4,78
|
|
|
|
18 |
 |
Spring 13 mm for stop screw, Bing 60-280 (bare steel) | 0039170 |
13110039170 |
|
2 |
€2,18
|
|
|
|
|
 |
Spring 15 mm for stop screw, Bing 60-282 | 0039171 |
13110039171 |
|
2 |
€1,27
|
|
|
|
19 |
 |
Stop screw for carburetor slide Bing 50-085, M6 x 0.75, L = 37 mm | 0039527 |
13110039527 |
|
2 |
€8,13
|
|
|
|
|
 |
Alu-bronze threaded bushing M7 / M6 x 0.75 for needle jet and slide stop screw ►see details | 0039123.6 |
13110039123.6 |
|
1 |
€34,55
|
|
|
|
20 |
 |
Carburetor idle jet , Bing 44-031 | 0039137 |
13110039137 |
|
2 |
€9,14
|
|
|
|
21 |
 |
Gasket ring Bing 65-102 | 0042126 |
13110042126 |
|
2 |
€0,61
|
|
|
|
22 |
 |
Screw plug M7 x 0.75 Bing 140-706 | 0039196 |
13110039196 |
M7x0.75 |
2 |
€3,15
|
|
|
|
23 |
 |
Needle jet 1208 Bing 45-251 (Ø 2.64 mm) | 0039123 |
13110039123 |
R50S, R69 |
2 |
€20,15
|
|
|
|
|
 |
Needle jet 1308 Bing 45-251 (Ø 2.68 mm) ►see details | 0039124 |
13110039124 |
R50, R50/2, R60, R60/2 |
2 |
€19,48
|
|
|
|
|
 |
Needle jet 2108 Bing 45-251 - M6 x 0.75 | 0039129 |
13110039129 |
R69S |
2 |
€20,45
|
|
|
|
|
|
Alu-bronze threaded bushing M7 / M6 x 0.75 for needle jet and slide stop screw ►see details | 0039123.6 |
13110039123.6 |
|
1 |
€34,55
|
|
|
|
24 |
 |
Carburetor main jet 110, Bing 44-051 (D~1.03 mm) | 0039144 |
13110039144 |
R60/2 |
2 |
€8,62
|
|
|
|
|
 |
Carburetor main jet 115, Bing 44-051 (D~1.03 mm) | 0039245 |
13110039245 |
R69, R60 Sidecar |
2 |
€10,83
|
|
|
|
|
 |
Carburetor main jet 120, Bing 44-051 (D~1.08 mm) | 0039241 |
13110039241 |
R50, R50/2 |
2 |
€9,74
|
|
|
|
|
 |
Carburetor main jet 123 (D~1.10 mm), after-market | 1336839 |
13111336839 |
R50, R50/2, R60, R60/2 |
2 |
€4,36
|
|
|
|
|
 |
Carburetor main jet 125, Bing 44-051 (D~1.12 mm) | 0039147 |
13110039147 |
R60, R60/2 |
2 |
€9,74
|
|
|
|
|
 |
Carburetor main jet 130, Bing 44-051 (D~1.22 mm) | 0039141 |
13110039141 |
R50S, R69S |
2 |
€9,74
|
|
|
|
|
 |
Carburetor main jet 135, Bing 44-051 (D~1.23 mm) | 0039239 |
13110039239 |
R50S, R69S Sidecar |
2 |
€8,62
|
|
|
|
25 |
 |
Gasket ring for main jet cover screw | 0042130 |
13110042130 |
|
2 |
€0,35
|
|
|
|
26 |
 |
Screw cap main jet M15 x 1, Bing 50-250 | 0039197 |
13110039197 |
M15x1 |
2 |
€10,95
|
|
|
|
|
 |
Screw cap Bing 50-240, M15 x 1 (short model) | 0039199 |
13110039199 |
M15x1 |
2 |
€7,56
|
|
|
|
27 |
 |
Screw cap (thread Ø 13 mm x 0.8), Bing 50-200 | 0039198 |
13110039198 |
|
2 |
€6,95
|
|
|
|
|
 |
Screw cap Ø20 mm Bing 50-203 | 0039195 |
13110039195 |
R50/2, R50S, R60/2, R69S |
2 |
€13,98
|
|
|
|
28 |
 |
Gasket ring Ø13 mm Bing | 0042134 |
13110042134 |
|
2 |
€0,85
|
|
|
|
|
 |
Gasket ring Ø 20 mm Bing | 0042135 |
13110042135 |
R50/2, R50S, R60/2, R69S |
2 |
€0,54
|
|
|
|
29 |
 |
Tickler spring Bing 60-048 Ø = 4.5, L = 35 mm | 0039164 |
13110039164 |
|
2 |
€0,54
|
|
|
|
|
 |
Split pin for tickler, Bing 49-030 | 0039165 |
13110039165 |
R50, R60, R69 old model cover |
2 |
€0,61
|
|
|
|
30 |
 |
Circlip for tickler Bing | 0039262 |
13110039262 |
|
2 |
€0,87
|
|
|
|
31 |
 |
Tickler for BING carburetor R51/2 - R69S | 0039260 |
13110039260 |
|
2 |
€8,77
|
|
|
|
|
 |
Tickler (plastic cap) ►see details for related parts | 1252177 |
13111252177 |
R50/2, R50S, R60/2, R69S |
2 |
€9,50
|
|
|
|
x |
|
Circlip for tickler Bing | 0039262 |
13110039262 |
depending on tickler model |
2 |
€0,87
|
|
|
|
x |
 |
Safety washer for tickler Bing | 0039262.A |
13110039262.A |
depending on tickler model |
2 |
€0,36
|
|
|
|
x |
 |
Split pin 1.2 x 10 mm - SSt | 9945055.1 |
07119945055.1 |
depending on tickler model |
2 |
€0,18
|
|
|
|
(29) |
|
Tickler spring Bing 60-048 Ø = 4.5, L = 35 mm | 0039164 |
13110039164 |
|
2 |
€0,54
|
|
|
|
32 |
 |
Hex screw M5 x 13 mm for float chamber cover, Bing 40-528 | 0039156 |
13110039156 |
|
4 |
€7,32
|
|
|
|
32 |
 |
Hex screw M5 x 13 mm for float chamber cover, Bing 40-528 - SSt | 0039156.1 |
13110039156.1 |
|
1 |
€6,90
|
|
|
|
32 |
 |
Hex screw M5 x 13 mm for float chamber cover, Bing 40-528 - polished SSt | 0039156.4 |
13110039156.4 |
|
4 |
€8,59
|
|
|
|
x |
 |
Spring washer for carburetor, Bing 61-680 | 0039193 |
13110039193 |
for nr. 32 hex screw |
4 |
€0,35
|
|
|
|
33 |
 |
Float housing cover, complete - Bing 32-310-112 ►see details | 1252176 |
13111252176 |
|
2 |
€106,96
|
|
|
|
34 |
 |
Gasket float chamber Bing 165-540 | 0042150AHN |
13110042150A |
|
2 |
€1,63
|
|
|
|
35 |
 |
Float needle, Bing 47-965 (early model) | 0039288 |
13110039288 |
|
2 |
€10,22
|
|
|
|
|
 |
Float needle, Bing 47-334 | 1252178 |
13111252178 |
R50/2, R50S, R60/2, R69S |
2 |
€2,72
|
|
|
|
36 |
 |
Float 7 gram, Bing 35-072 | 0039187 |
13110039187 |
|
2 |
€51,85
|
|
|
|
37 |
 |
Float needle - metal tip, Bing 40-056 | 1251394 |
13111251394 |
R50/2, R50S, R60/2, R69S |
2 |
€9,86
|
|
|
|
37 |
 |
Float needle - rubber tip, Bing 47-030 (new model) | 1251394.R |
13111251394.R |
R50/2, R50S, R60/2, R69S |
2 |
€19,60
|
|
|
|
38 |
 |
Lever for tickler, Bing 57-350 | 1251395 |
13111251395 |
R50/2, R50S, R60/2, R69S |
2 |
€12,95
|
|
|
|
39 |
 |
Pin for lever, Bing 52-050 | 1251396 |
13111251396 |
R50/2, R50S, R60/2, R69S |
2 |
€7,11
|
|
|
|
40 |
 |
Shim for carburetor guide pin - aluminum | 1252179 |
13111252179 |
R50/2, R50S, R60/2, R69S |
2 |
€7,62
|
|
|
|
41 |
 |
Flat washer Ø 8.4 mm - SSt | 9931067.1 |
07119931067.1 |
R50S, R69, R69S |
4 |
€0,18
|
|
|
|
42 |
 |
Wave washer B8 | 9932090 |
07119932090 |
R50, R50/2, R60, R60/2 |
4 |
€0,12
|
|
|
|
43 |
 |
Hex nut M8 x 1.25 | 9922081 |
07119922081 |
M8 |
4 |
€0,15
|
|
|
|
44 |
 |
Centering bushing carburetor flange | 0043168 |
11610043168 |
R50S, R69S |
2 |
€6,17
|
|
|
|
45 |
 |
Hex nut for cable adjusting screw Bing 42-605 | 0039182 |
13110039182 |
|
2 |
€1,03
|
|
|
|
46 |
 |
Carburetor 1/24/150 - RH side - R50, R50/2 (discontinued by BING) | 0039073 |
13110039073 |
R50, R50/2 |
1 |
€0,00
|
|
|
|
|
 |
Carburetor 1/24/149 - LH side (discontinued by BING) | 0039074 |
13110039074 |
R50, R50/2 |
1 |
€0,00
|
|
|
|
|
 |
Carburetor 1/24/152 - RH side - R60, R60/2 (discontinued by BING) | 0039076 |
13110039076 |
R60, R60/2 |
1 |
€0,00
|
|
|
|
|
 |
Carburetor 1/24/151 - LH side - R60, R60/2 (discontinued by BING) | 0039077 |
13110039077 |
R60, R60/2 |
1 |
€0,00
|
|
|
|
|
 |
Carburetor 1/26/92 - RH side (discontinued by BING) | 0039056 |
13110039056 |
R69S |
1 |
€0,00
|
|
|
|
|
 |
Carburetor 1/26/91 - LH side (discontinued by BING) | 0039057 |
13110039057 |
R69S |
1 |
€0,00
|
|
|
|
|
|
NOS Carburetor slide cover plate, LH side, Bing 20-351 (on request only) |
|
|
R50/2, R50S, R60/2, R69, R69S |
1 |
Not available |
|
|
|
|
|
Carburetor overhaul 2x |
|
|
R69 |
1 |
Not available |
|
|
