x |
 |
Gasket set carburetor - all 2 cyl. | 5590039 |
13115590039 |
all models |
2 |
€4,78
|
|
|
|
1 |
 |
Cover ring, M34 x 1 - 13 mm height, Bing 21-502 | 0039215 |
13110039215 |
R51/2 - R67/3 |
2 |
€21,18
|
|
|
|
|
 |
Cover ring, M38 x 1 - 13 mm height, Bing 21-542 | 0039216 |
13110039216 |
R68 |
2 |
€37,75
|
|
|
|
2 |
 |
Rubber O-ring Bing 65-730 | 0042149 |
13110042149 |
|
2 |
€3,05
|
|
|
|
3 |
 |
Carburetor slide cover plate, LH side, Bing 30-320, after-market | 0039111 |
13110039111 |
R51/2 - R67/3 |
1 |
€82,28
|
|
|
|
|
 |
Carburetor slide cover plate, RH side, Bing 30-322, after-market | 0039112 |
13110039112 |
R51/2 - R67/3 |
1 |
€82,28
|
|
|
|
|
 |
Cover for carburetor L/R (for M38 cover ring) ►see details | 0039219.3 |
13110039219.3 |
R68 |
1 |
€51,73
|
|
|
|
4 |
 |
Rubber boot for throttle cable at carburetor | 0042111 |
13110042111 |
|
2 |
€2,53
|
|
|
|
5 |
 |
Cable adjusting screw on carburetor, 25 mm (Bing 50-050) | 0039178 |
13110039178 |
|
2 |
€3,51
|
|
|
|
6 |
 |
Slide valve spring Bing 60-110, L = 65 mm, D = 6.1 mm | 0039169 |
13110039169 |
|
2 |
€1,19
|
|
|
|
7 |
 |
Needle Bing 46-921, old model | 0039172 |
13110039172 |
R51/2, R51/3 |
2 |
€13,25
|
|
|
|
|
 |
Needle no. 2 Bing 46-932 (from 08-1953) | 0039174 |
13110039174 |
R67 - R67/3 |
2 |
€8,59
|
|
|
|
|
 |
Carburetor slide needle no. 4 Bing 46-934 | 0039272 |
13110039272 |
R68 |
2 |
€9,38
|
|
|
|
|
 |
Carburetor slide needle - Bing 46-255 | 0039274 |
13110039274 |
R51/3 - R68 |
2 |
€19,32
|
|
|
|
8 |
 |
Retaining clip, early model Bing 61-400 | 0039175 |
13110039175 |
|
2 |
€2,72
|
|
|
|
9 |
 |
Retaining clip, Bing 61-375 | 0039176 |
13110039176 |
|
2 |
€6,72
|
|
|
|
10 |
 |
Carburetor slide 27 mm Bing 22-460 | 0039119 |
13110039119 |
R51/2 - R67/3 |
2 |
€38,60
|
|
|
|
|
 |
Carburetor slide Ø 29.4 mm Bing 22-542 ►see details | 0039116 |
13110039116 |
R68 |
2 |
€59,41
|
|
|
|
11 |
 |
Insert Bing 25-015-5 (Nr. 5) | 0039127 |
13110039127 |
R51/2 - R67/3 |
2 |
€62,92
|
|
|
|
12 |
 |
Flange gasket carburetor & cyl. head R25 - R25/3, R51/3 - R67/3, R50 - R60/2 | 0042146 |
13110042146 |
R51/2 - R67/3 |
2 |
€8,53
|
|
|
|
|
 |
Flange gasket carburetor & cyl. head R68, R50S, R69, R69S | 0042147 |
13110042147 |
R68 |
2 |
€9,56
|
|
|
|
14 |
 |
Jam nut for idle mix screw and cable guide, Bing 42-702 | 0039184 |
13110039184 |
|
2 |
€0,92
|
|
|
|
15 |
 |
Idle mix screw (short), Bing 50-016 | 0039180 |
13110039180 |
R51/2 |
2 |
€14,64
|
|
|
|
|
 |
Idle mix screw, Bing 50-920 | 0039181 |
13110039181 |
R51/3 - R68 |
2 |
€11,92
|
|
|
|
16 |
 |
Idle mix screw cap, Bing 57-560 | 0039185 |
13110039185 |
R51/3 - R68 |
2 |
€3,35
|
|
|
|
17 |
 |
Idle mix screw sleeve, Bing 50-520 | 0039183 |
13110039183 |
R51/3 - R68 |
2 |
€4,78
|
|
|
|
18 |
 |
Spring 13 mm for stop screw, Bing 60-280 (bare steel) | 0039170 |
13110039170 |
|
2 |
€2,18
|
|
|
|
19 |
 |
Stop screw for carburetor slide Bing 50-085, M6 x 0.75, L = 37 mm | 0039527 |
13110039527 |
|
2 |
€8,13
|
|
|
|
|
 |
Stop screw for carburetor slide, M6 x 0.75, L = 32 mm | 0039151 |
13110039151 |
|
2 |
€8,65
|
|
|
|
|
 |
Alu-bronze threaded bushing M7 / M6 x 0.75 for needle jet and slide stop screw ►see details | 0039123.6 |
13110039123.6 |
|
1 |
€34,55
|
|
|
|
|
 |
Carburetor idle jet , Bing 44-031 | 0039137 |
13110039137 |
R51/2 |
2 |
€9,14
|
|
|
|
20 |
 |
Idle jet R25, R51/2 | 0039140 |
13110039140 |
R51/2 |
2 |
€25,77
|
|
|
|
21 |
 |
Gasket ring Bing 65-102 | 0042126 |
13110042126 |
|
2 |
€0,61
|
|
|
|
22 |
 |
Screw plug M7 x 0.75 Bing 140-706 | 0039196 |
13110039196 |
|
2 |
€3,15
|
|
|
|
23 |
 |
Needle jet 1208 Bing 45-251 (Ø 2.64 mm) | 0039123 |
13110039123 |
|
2 |
€20,15
|
|
|
|
|
 |
Needle jet 1308 Bing 45-251 (Ø 2.68 mm) ►see details | 0039124 |
13110039124 |
|
2 |
€19,48
|
|
|
|
|
|
Alu-bronze threaded bushing M7 / M6 x 0.75 for needle jet and slide stop screw ►see details | 0039123.6 |
13110039123.6 |
|
1 |
€34,55
|
|
|
|
23b |
 |
Threaded insert Bing 50-390 | 0039194 |
13110039194 |
<>R67/3 |
2 |
€11,19
|
|
|
|
24 |
 |
Carburetor main jet 90, Bing 44-101, M6 SW8 (D~0.83 mm) | 0039243 |
13110039243 |
R51/2 |
2 |
€8,62
|
|
|
|
|
 |
Carburetor main jet 100, Bing 44-051 (D~0.93 mm) | 0039143 |
13110039143 |
R51/2, R51/3 |
2 |
€9,20
|
|
|
|
|
 |
Carburetor main jet 110, Bing 44-051 (D~1.03 mm) | 0039144 |
13110039144 |
R67 - R67/3 |
2 |
€8,62
|
|
|
|
|
 |
Carburetor main jet 105 (D~0.97 mm) | 1337062 |
13111337062 |
R51/3 |
2 |
€8,62
|
|
|
|
|
 |
Carburetor main jet 115, Bing 44-051 (D~1.03 mm) | 0039245 |
13110039245 |
R68 |
2 |
€10,83
|
|
|
|
25 |
 |
Gasket ring for main jet cover screw | 0042130 |
13110042130 |
|
2 |
€0,35
|
|
|
|
26 |
 |
Screw cap main jet M15 x 1, Bing 50-250 | 0039197 |
13110039197 |
M15x1 |
2 |
€10,95
|
|
|
|
27 |
 |
Screw cap (thread Ø 13 mm x 0.8), Bing 50-200 | 0039198 |
13110039198 |
|
2 |
€6,95
|
|
|
|
|
 |
Screw cap Ø20 mm Bing 50-203 | 0039195 |
13110039195 |
1/24/141, 142, 159, 169 |
2 |
€13,98
|
|
|
|
28 |
 |
Gasket ring Ø13 mm Bing | 0042134 |
13110042134 |
|
2 |
€0,85
|
|
|
|
|
 |
Gasket ring Ø 20 mm Bing | 0042135 |
13110042135 |
1/24/141, 142, 159, 169 |
2 |
€0,54
|
|
|
|
29 |
 |
Tickler spring Bing 60-048 Ø = 4.5, L = 35 mm | 0039164 |
13110039164 |
|
2 |
€0,54
|
|
|
|
|
 |
Split pin for tickler, Bing 49-030 | 0039165 |
13110039165 |
old model cover |
2 |
€0,61
|
|
|
|
30 |
 |
Circlip for tickler Bing | 0039262 |
13110039262 |
|
2 |
€0,87
|
|
|
|
31 |
 |
Tickler for BING carburetor R51/2 - R69S | 0039260 |
13110039260 |
|
2 |
€8,77
|
|
|
|
x |
|
Circlip for tickler Bing | 0039262 |
13110039262 |
depending on tickler model |
2 |
€0,87
|
|
|
|
x |
 |
Split pin 1.2 x 10 mm - SSt | 9945055.1 |
07119945055.1 |
depending on tickler model |
2 |
€0,18
|
|
|
|
x |
 |
Safety washer for tickler Bing | 0039262.A |
13110039262.A |
depending on tickler model |
2 |
€0,36
|
|
|
|
32 |
 |
Hex screw M5 x 13 mm for float chamber cover, Bing 40-528 | 0039156 |
13110039156 |
|
4 |
€7,32
|
|
|
|
x |
 |
Spring washer for carburetor, Bing 61-680 | 0039193 |
13110039193 |
for nr. 32 hex screw |
4 |
€0,35
|
|
|
|
33 |
 |
Float housing cover, complete - Bing 32-310-112 ►see details | 1252176 |
13111252176 |
R51/3 - R68 |
2 |
€106,96
|
|
|
|
34 |
|
Gasket float chamber Bing 165-540 |
|
|
|
2 |
Not available |
|
|
|
34 |
 |
Gasket float chamber Bing 165-540 | 0042150AHN |
13110042150A |
|
1 |
€1,63
|
|
|
|
35 |
 |
Float needle, Bing 47-965 (early model) | 0039288 |
13110039288 |
early models |
2 |
€10,22
|
|
|
|
|
 |
Float needle, Bing 47-334 | 1252178 |
13111252178 |
|
2 |
€2,72
|
|
|
|
36 |
 |
Float 7 gram, Bing 35-072 | 0039187 |
13110039187 |
|
2 |
€51,85
|
|
|
|
37 |
 |
Centering bushing carburetor flange | 0043168 |
11610043168 |
R68 |
2 |
€6,17
|
|
|
|
38 |
 |
Hex nut for cable adjusting screw Bing 42-605 | 0039182 |
13110039182 |
|
2 |
€1,03
|
|
|
|
39 |
|
Flat washer Ø 8.4 mm |
|
|
8.4 |
4 |
Not available |
|
|
|
40 |
 |
Wave washer B8 | 9932090 |
07119932090 |
|
4 |
€0,12
|
|
|
|
41 |
 |
Hex nut M8 x 1.25 | 9922081 |
07119922081 |
M8 |
4 |
€0,15
|
|
|
|
|
 |
Carburetor set 1/24/159 & 160 - R51/2, R51/3 (discontinued) | 0039026 |
13110039026 |
R51/3 |
1 |
€0,00
|
|
|
|
|
|
Carburetor set 1/24/159 & 160 - R51/2, R51/3 - NEW |
|
|
R51/3 |
1 |
Not available |
|
|
|
|
|
Carburetor set 1/24/159 & 160 - R51/2, R51/3 (discontinued) | 0039026 |
13110039026 |
R51/2, R51/3 |
1 |
€0,00
|
|
|
|
|
|
Carburetor set 1/24/159 & 160 - R51/2, R51/3 - NEW |
|
|
R51/2, R51/3 |
1 |
Not available |
|
|
|
|
|
Carburetor set 1/24/141 & 142 - R67/2, R67/3 - NEW |
|
|
R67/2, R67/3 |
1 |
Not available |
|
|
|
|
|
Carburetor set 1/24/141 & 142 - R67/2, R67/3 - NOS |
|
|
R67/2, R67/3 |
1 |
Not available |
|
|
|
|
|
Carburetor overhaul 2x |
|
|
R68 |
1 |
Not available |
|
|
|
|
 |
Carburetor 1/26/92 - RH side (discontinued by BING) | 0039056 |
13110039056 |
R68 |
1 |
€0,00
|
|
|
|
|
 |
Carburetor 1/26/91 - LH side (discontinued by BING) | 0039057 |
13110039057 |
R68 |
1 |
€0,00
|
|
|
|
b |
|
Split pin 1.2 x 10 mm - SSt | 9945055.1 |
07119945055.1 |
depending on tickler model |
1 |
€0,18
|
|
|
|
|
|
NOS Carburetor slide cover plate, LH side, Bing 20-351 (on request only) |
|
|
R68 |
1 |
Not available |
|
|
