1 |
 |
Ball bearing FAG 6203, crankshaft & camshaft ►see details | 9981213 |
07119981213 |
R50, R60, R69 (17 mm taper) |
1 |
€3,93
|
|
|
|
|
 |
Crankshaft roller bearing FAG 6004 in distribution cover | 9981044 |
07119981044 |
R50/2, R50S, R60/2, R69S |
1 |
€3,51
|
|
|
|
2 |
 |
Lock ring A25 x 1.2 mm | 9934171 |
07119934171 |
A25x1.2 mm |
1 |
€0,58
|
|
|
|
3 |
 |
Shim for crankshaft gear | 0016201.A |
11210016201.A |
R50 |
1 |
€3,81
|
|
|
|
4 |
 |
Ball bearing FAG 6207 M for crankshaft - brass cage ►see details!! | 9981245 |
07119981245 |
|
1 |
€94,56
|
|
|
|
5 |
 |
Spacer washer | 3038126 |
26113038126 |
R50/2, R60/2, R69S (reinf. crank) |
1 |
€3,81
|
|
|
|
6 |
 |
Spacer ring for front bearing bushing | 0016244 |
11210016244 |
R50, R60 |
1 |
€12,95
|
|
|
|
7 |
 |
Spacer ring inner | 0016240.5 |
11210016240.5 |
R50, R60 |
1 |
€3,27
|
|
|
|
8 |
 |
Spacer ring crankshaft with chamfer 4.2 mm | 0016212 |
11210016212 |
R50, R60 |
1 |
€7,87
|
|
|
|
9 |
 |
Countersunk screw M6 x 10 for oil slinger ►see details | 9900106 |
07119900106 |
6x10 mm |
2/4 |
€2,36
|
|
|
|
10 |
 |
Oil slinger R51/2, R51/3, R50 | 0016216 |
11210016216 |
R50 |
2 |
€20,03
|
|
|
|
|
 |
Oil slinger R67 - R60 ►see details | 0016217 |
11210016217 |
R60 |
2 |
€19,00
|
|
|
|
|
 |
Oil slinger R50/2, R50S ►see details | 0016219 |
11210016219 |
R50/2, R50S |
2 |
€17,85
|
|
|
|
|
 |
Oil slinger R68, R69 | 0016218 |
11210016218 |
R69 (original model) |
2 |
€27,41
|
|
|
|
|
 |
Oil slinger R60/2, R69S | 0016221 |
11210016221 |
R60/2, R69, R69S |
2 |
€32,37
|
|
|
|
12 |
 |
Crankpin 32 x 50 mm - 1 side tapered (available for pre-order) | 0016234 |
11210016234 |
R50 |
2 |
€79,75
|
|
|
|
|
 |
Crankpin 36 x 50 mm - 1 side tapered | 0016233 |
11210016233 |
R60 |
2 |
€79,75
|
|
|
|
|
 |
Crankpin 36 x 53 mm - 1 side tapered (available for pre-order) | 0016231 |
11210016231 |
R69 |
2 |
€83,55
|
|
|
|
|
 |
Crankpin 32 x 53 mm - cylindrical (available for pre-order) | 0016262 |
11210016262 |
R50/2, R50S |
2 |
€75,69
|
|
|
|
|
 |
Crankpin 36 x 36 x 53 mm - cylindrical - FAG Dürkopp | 0016243 |
11210016243 |
R60/2, R69S |
2 |
€79,75
|
|
|
|
|
 |
Crankpin 36 x 54.5 mm - cylindrical - for reinforced crankshaft | 0016263 |
11210016263 |
R60/2, R69S |
2 |
€138,55
|
|
|
|
14 |
 |
Woodruff key 5 x 6.5 mm | 9951480 |
07119951480 |
5x6.5 mm |
1 |
€1,63
|
|
|
|
15,16,17 |
|
Crankshaft overhaul R51/2 - R68, R50 - R69S, option 1 ►see details |
|
|
R50 |
1 |
Not available |
|
|
|
|
|
Crankshaft overhaul R50S - option 1 ►see details |
|
|
R50S |
1 |
Not available |
|
|
|
|
|
Crankshaft overhaul R50/2 - option 2 ►see details |
|
|
R50/2 |
1 |
Not available |
|
|
|
|
 |
Crankshaft complete, new production | 0016045 |
11210016045 |
R60 |
1 |
€1.189,66
|
|
|
|
|
|
Crankshaft new, 125 mm conrod |
|
|
R60/2 |
1 |
Not available |
|
|
|
|
|
Crankshaft overhaul R68, R69 - option 1 ►see details |
|
|
R69 |
1 |
Not available |
|
|
|
|
|
Crankshaft, overhauled, with new connecting rods - in exchange |
|
|
R69S |
1 |
Not available |
|
|
|
18 |
 |
Woodruff key 5 x 4.4 mm - flywheel | 0016132 |
11210016132 |
5x4.4 mm |
1 |
€2,78
|
|
|
|
19 |
 |
Roller for conrod Ø 7.020 x 10 mm ±1μ (available from Salis Services) | 0016143.02 |
11240016143.02 |
R50, R60 |
24/28 |
€0,00
|
|
|
|
19b |
 |
Roller for conrod Ø 7.01 x 10 mm ±1μ (available from Salis Services) | 0016143.01 |
11240016143.01 |
R50, R60 |
1 |
€0,00
|
|
|
|
19c |
 |
Roller for conrod Ø 7.030 x 10 mm ±2μ (available from Salis Services) | 0016143.03 |
11240016143.03 |
R50, R60 |
1 |
€0,00
|
|
|
|
19d |
 |
Roller for conrod Ø 7.039 x 10 mm ±1μ (available from Salis Services) | 0016143.04 |
11240016143.04 |
R50, R60 |
1 |
€0,00
|
|
|
|
19e |
 |
Roller for conrod Ø 7.054 x 10 mm ±2μ (available from Salis Services) | 0016143.06 |
11240016143.06 |
R50, R60 |
1 |
€0,00
|
|
|
|
19f |
 |
Roller for conrod Ø 7.048 x 10 mm ±2μ (available from Salis Services) | 0016143.05 |
11240016143.05 |
R50, R60 |
1 |
€0,00
|
|
|
|
19g |
 |
Roller for conrod Ø 7.000 x 10 mm ±2μ (available from Salis Services) | 0016143.C |
11240016143.C |
R50, R60 |
1 |
€0,00
|
|
|
|
19h |
 |
Roller for conrod Ø 7.049 x 10 mm ±2μ (available from Salis Services) | 0016143.D |
11240016143.D |
R50, R60 |
1 |
€0,00
|
|
|
|
19i |
 |
Roller for conrod Ø 6.992 x 10 mm ±1μ (available from Salis Services) | 0016143.A |
11240016143.A |
R50, R60 |
1 |
€0,00
|
|
|
|
19j |
 |
Roller for conrod Ø 7.003 x 10 mm ±2μ (available from Salis Services) | 0016143.E |
11240016143.E |
R50, R60 |
1 |
€0,00
|
|
|
|
19k |
 |
Roller for conrod Ø 7.025 x 10 mm ±2μ (available from Salis Services) | 0016143.025 |
11240016143.025 |
R50, R60 |
1 |
€0,00
|
|
|
|
19l |
 |
Roller for conrod Ø 6.995 x 10 mm ±1μ (available from Salis Services) | 0016143.B |
11240016143.B |
R50, R60 |
1 |
€0,00
|
|
|
|
|
 |
Roller for conrod Ø 4.995 x 10 mm ±1μ (available from Salis Services) | 0016824 |
11240016824 |
R50/2 - R69S |
32/36 |
€0,00
|
|
|
|
20 |
 |
Roller cage for 32 mm Ø crankpin 16 x 5 mm rollers- big end bearing | 0016125 |
11210016125 |
R50/2 , R50S |
2 |
€41,38
|
|
|
|
|
 |
Roller cage for crankpin 12 x 7 mm rollers - big end bearing | 0016128 |
11210016128 |
R50 |
2 |
€51,43
|
|
|
|
|
 |
Bearing cage for conrod - for 36 mm crankpin and 46 mm conrod - 16 x 5 mm rollers ►see details | 0017720 |
11240017720 |
R60 - R69S |
2 |
€76,23
|
|
|
|
21 |
 |
Set of connecting rod, cylindrical crankpin (Ø 36 x 53), roller cage & rollers | 0017032C |
11240017032C |
R60, R69, R69S |
2 |
€359,79
|
|
|
|
21b |
|
Set of connecting rod, cylindrical crankpin (Ø 36 x 53), roller cage & rollers | 0017032C |
11240017032C |
R60, R69, R69S |
1 |
€359,79
|
|
|
|
21c |
 |
Set of connecting rod 130 mm, 20 mm wrist pin, tapered crankpin (Ø 36 x 50 mm), roller cage & rollers - not available for the time being | 0017032A |
11240017032A |
R60, R69, R69S |
1 |
€359,79
|
|
|
|
21d |
 |
Set of connecting rod, cylindrical crankpin (Ø 36 x 54.5), roller cage & rollers - not available for the time being | 0017032D |
11240017032D |
R60, R69, R69S |
1 |
€359,79
|
|
|
|
|
 |
Set of connecting rod, cylindrical crank pin, roller cage & rollers (available for pre-order) | 0017052B |
11240017052B |
R50/2, R50S |
2 |
€359,79
|
|
|
|
|
 |
Set of connecting rod, tapered crankpin (Ø 32 x 50), roller cage & rollers | 0017701A |
11240017701A |
R50, R60/2 |
2 |
€377,58
|
|
|
|
22 |
 |
Wrist pin bushing - 20 mm (needs reaming after press fit) | 0017150 |
11240017150 |
20 mm |
2 |
€10,77
|
|
|
|
23 |
|
Ball bearing FAG 6207 M for crankshaft - brass cage ►see details!! | 9981245 |
07119981245 |
R50, R50/2, R60, R60/2 |
1 |
€94,56
|
|
|
|
24 |
 |
Crankshaft main bearing rear 20207 C3 +Mark+Swiss | 9983301 |
07119983301 |
R50S, R69, R69S |
1 |
€166,90
|
|
|
|
26 |
|
Spacer ring crankshaft with chamfer 4.2 mm | 0016212 |
11210016212 |
R50, R60 |
1 |
€7,87
|
|
|
|
|
 |
Spacer washer with chamfer ~ 2 mm | 0016266 |
11210016266 |
R50/2, R50S, R60/2, R69, R69S |
1 |
€5,59
|
|
|
|
28 |
 |
Splash ring | 0016252 |
11210016252 |
|
1 |
€6,47
|
|
|
|
29 |
 |
Wave washer crankshaft - flywheel | 0016130 |
11210016130 |
|
1 |
€4,30
|
|
|
|
30 |
 |
Used part: Flywheel R50 - R60/2 (price & availability on request) | 0068037.U |
11220068037.U |
R50 - R60/2 |
1 |
€0,00
|
|
|
|
|
 |
Flywheel - steel 4 kg - after market ►see details | 0068038 |
11220068038 |
R69, R69S |
1 |
€274,85
|
|
|
|
|
 |
Flywheel sports version - aluminum 1.95 kg ►see details | 0068038.A |
11220068038.A |
R50 - R69S |
1 |
€331,00
|
|
|
|
31 |
 |
Lock plate for hex. head screw flywheel Ø 21.7 mm ►see details!! | 0016225 |
11210016225 |
|
1 |
€5,38
|
|
|
|
32 |
 |
Hex. head screw flywheel / crankshaft, SW41 - M18 x 1.5 | 0016251 |
11220016251 |
|
1 |
€18,33
|
|
|
|
|
 |
Spacer ring crankshaft front with chamfer | 0016268/3.6 |
11210016268/3.6 |
R50/2, R50S, R60/2, R69, R69S |
1 |
€4,36
|
|
|
