1 |
 |
Adjusting screw steering damper, chromed alum. with SSt rod | 2000045 |
31422000045 |
|
1 |
€72,42
|
|
|
|
2 |
 |
Steering head lock cap - chrome | 2000114 |
31422000114 |
h=19 mm - chrome |
1 |
€21,42
|
|
|
|
3 |
 |
Damper safety washer | 2000245 |
31422000245 |
|
1 |
€17,25
|
|
|
|
4 |
 |
Damping washer, set of 2 with rivets ►see details | 2000235 |
31412000235 |
set |
1 |
€11,86
|
|
|
|
5 |
 |
Split pin 2 x 20 mm - SSt | 9945111.1 |
07119945111.1 |
2x20 |
1 |
€0,17
|
|
|
|
6 |
 |
Pressure plate steering damper R25/3 | 2000230 |
31422000230 |
|
1 |
€28,01
|
|
|
|
7 |
 |
Rubber ring for steering damper anchor bolt - original BMW | 2000257 |
31422000257 |
|
2 |
€3,93
|
|
|
|
8 |
 |
Friction plate for steering damper | 2000219 |
31422000219 |
|
1 |
€21,84
|
|
|
|
10 |
 |
Washer for damper anchor bolt | 9931851.1 |
07119931851.1 |
|
1 |
€5,57
|
|
|
|
11 |
 |
Bolt for steering damper - SSt | 2000253.1 |
31422000253.1 |
|
1 |
€9,14
|
|
|
|
12 |
 |
Cap screw for front fork, aluminum, R25/3 | 2000243 |
31422000243 |
|
2 |
€20,51
|
|
|
|
13 |
 |
Screw plug fork tube | 2054128 |
31422054128 |
|
2 |
€41,02
|
|
|
|
15 |
 |
Headlight bracket, right - R25/3 | 2000199 |
31422000199 |
|
1 |
€62,07
|
|
|
|
16 |
 |
Lower fork tube bracket, right (price & availability on request) | 2000278 |
31412000278 |
|
1 |
€0,00
|
|
|
|
17 |
 |
Fork bridge upper lock nut | 2000101 |
31412000101 |
|
1 |
€11,92
|
|
|
|
18 |
 |
Lower hex nut, steering head i.c.w. tapered roller bearing set 31422000000 | 2000182.K |
31422000182.K |
replaced by 31412000181.K |
1 |
€26,98
|
|
|
|
19 |
 |
Protection cap upper steering head | 2000184 |
31412000184 |
|
1 |
€11,86
|
|
|
|
20,21,22,23,26 |
 |
Tapered roller bearing set for steering head (2 pcs) | 2000000 |
31422000000 |
upper & lower steering head |
1 |
€70,16
|
|
|
|
|
 |
Adjustment lock nut steering head, i.c.w. tapered roller bearing set nr. 31422000000 | 2000181.K |
31412000181.K |
i.c.w. 31422000000 |
1 |
€13,61
|
|
|
|
21 |
 |
Ball cage for steering head (discontinued) | 2000193 |
31412000193 |
|
2 |
€5,17
|
|
|
|
22 |
|
Race with outer shoulder for steering head bearings |
|
|
|
1 |
Not available |
|
|
|
22 |
 |
Set of steering head ball bearings (discontinued) | 2000190S |
31412000190S |
|
1 |
€0,00
|
|
|
|
23 |
|
Race with outer shoulder for steering head bearings |
|
|
|
1 |
Not available |
|
|
|
25 |
 |
Clamping bolt in fork bridge, chrome | 2000160 |
31422000160 |
|
2 |
€18,39
|
|
|
|
x |
 |
Serrated washer J8.4 - SSt | 9936206.1 |
07119936206.1 |
J8.4 |
2 |
€0,21
|
|
|
|
x |
 |
Hex nut M8 x 1 SW14 - zinc plated | 9922094 |
07119922094 |
M8x1 |
2 |
€0,61
|
|
|
|
26 |
 |
Ball Ø 5.5 mm for steering head | 9986255 |
07119986255 |
Ø 5.5 mm |
48 |
€0,25
|
|
|
|
27 |
 |
Used part: lower fork bridge R25/3 (price & availability on request) | 2000210 |
31412000210 |
|
1 |
€0,00
|
|
|
|
28 |
 |
Fork tube | 2000289 |
31422000289 |
|
2 |
€0,00
|
|
|
|
29 |
 |
Front fork seal R25/3 | 2000285 |
31422000285 |
|
2 |
€18,31
|
|
|
|
30 |
 |
Rubber ring for headlight bracket R25/3 | 2000165 |
31422000165 |
|
6 |
€4,27
|
|
|
|
31 |
 |
Headlight bracket, left - R25/3 | 2000205 |
31422000205 |
|
1 |
€62,07
|
|
|
|
35 |
 |
Fork tube fairing, lower, chromed steel | 2000120 |
31422000120 |
|
2 |
€103,09
|
|
|
|
36 |
 |
Clamping screw for left tube bracket - SSt | 2000107.1 |
31412000107.1 |
|
1 |
€16,15
|
|
|
|
36b |
 |
Clamping screw for left tube bracket - polished SSt | 2000107.4RD |
31412000107.4 |
|
1 |
€19,42
|
|
|
|
37 |
 |
Lower fork tube bracket, left | 2000282 |
31412000282 |
|
1 |
€0,00
|
|
|
|
39 |
 |
Seal ring, lower, in front fork sliding tube | 2054144 |
31422054144 |
|
2 |
€2,72
|
|
|
|
40 |
 |
Washer B16 for front fork sliding tube, lower - SSt | 9932160 |
07119932160 |
|
2 |
€1,15
|
|
|
|
41 |
 |
Hex nut M16 x 1.5 - flat, for front fork - SSt | 2054148.1 |
31422054148.1 |
M16x1.5 |
2 |
€3,45
|
|
|
|
42 |
 |
Rubber/metal stop below front fork cap | 2054152 |
31422054152 |
|
1 |
€13,43
|
|
|
|
43 |
 |
Front suspension spring, solo & sidecar R25/3 | 2054004 |
31422054004 |
solo |
2 |
€25,89
|
|
|
|
44 |
 |
Clamping spring for front shock absorber | 2054160 |
31422054160 |
|
2 |
€7,56
|
|
|
|
46 |
 |
Washer gasket in fork sliding tube | 2054140 |
31422054140 |
|
2 |
€2,72
|
|
|
|
47 |
 |
Wave washer B8 | 9932090 |
07119932090 |
|
2 |
€0,12
|
|
|
|
48 |
|
Cap screw - SSt |
|
|
|
2 |
Not available |
|
|
|
49 |
 |
Pressure piece, front fork | 2054168 |
31422054168 |
|
2 |
€24,14
|
|
|
|
50 |
 |
Rubber washer | 2054156 |
31422054156 |
|
2 |
€1,55
|
|
|
|
51 |
 |
Threaded ring for shock absorber rod | 2054180 |
31422054180 |
|
2 |
€4,60
|
|
|
|
52 |
 |
Plug for front shock absorber | 2054164 |
31422054164 |
|
2 |
€9,20
|
|
|
|
54 |
 |
Used part: shock absorber rod R25/3 (price & availability on request) | 2054176 |
31422054176 |
|
2 |
€0,00
|
|
|
|
55 |
 |
Shock absorber valve Ø ~13.88 mm | 2054132 |
31422054132 |
|
2 |
€11,40
|
|
|
|
57 |
 |
Serrated washer J5.3 - zinc plated | 9936110 |
07119936110 |
J5.3 |
2 |
€0,10
|
|
|
|
|
 |
Spring washer B5 - SSt | 9933060.1 |
07119933060.1 |
B5 |
2 |
€0,10
|
|
|
|
58 |
 |
Hex nut M5 x 0.8 - SSt | 9922038SP |
07119922038.1 |
M5 |
2 |
€0,13
|
|
|
|
58 |
|
Hex nut M5 x 0.8 - SSt | 9922038SP |
07119922038.1 |
M5 |
1 |
€0,13
|
|
|
