1 |
 |
Fuel tank R26 & R27, base coated - original (available for pre-order) | 0035286 |
16110035286 |
primered |
1 |
€1.642,70
|
|
|
|
|
 |
Fuel tank R26 & R27, painted & coach-lined (not available anymore) | 0035287 |
16110035287 |
black with pin striping |
1 |
€0,00
|
|
|
|
2 |
 |
Filler cap, aluminum, original BMW (gaskets included) | 0035314 |
51250035314 |
aluminum |
11 |
€133,46
|
|
|
|
|
 |
Filler cap chrome (gasket ring included) | 4080126.C |
16114080126.C |
chrome |
1 |
€24,81
|
|
|
|
|
 |
Filler cap with lock - SSt | 4080127 |
16114080127 |
stainless steel |
1 |
€24,02
|
|
|
|
3 |
 |
Gasket for fuel cap, cork | 4080130 |
16114080130 |
|
1 |
€2,72
|
|
|
|
4 |
|
Key for toolbox lock screw - zinc plated |
|
|
|
1 |
Not available |
|
|
|
5 |
|
Lock screw for toolbox lid (>1952) - zinc plated |
|
|
|
1 |
Not available |
|
|
|
5b |
 |
Lock screw for toolbox lid (>1952) - SSt polished | 4080165.4 |
16114080165.4 |
|
1 |
€11,98
|
|
|
|
5c |
 |
Washer set for lock screw for toolbox lid (>1952) | 4080165.7 |
16114080165.7 |
|
1 |
€3,27
|
|
|
|
6 |
 |
Washer for lock screw toolbox lid - SSt | 9963107 |
07119963107 |
10x16 |
2 |
€2,15
|
|
|
|
7 |
 |
Toolbox lid, hinge at rear side, black | 4080170 |
16114080170 |
black |
1 |
€86,43
|
|
|
|
|
 |
Toolbox lid, hinge at bottom side, base coated | 1231298 |
16111231298 |
primered |
1 |
€60,32
|
|
|
|
8 |
 |
Gasket for toolbox lid ►see details | 4080188 |
16114080188 |
|
1 |
€10,83
|
|
|
|
9 |
 |
Hinge pin for toolbox lid 4 x 35 mm - SSt | 4080176.1 |
16114080176.1 |
|
2 |
€5,45
|
|
|
|
10 |
 |
Knee pad rubber on fuel tank, left side - R26, R27 | 4080183 |
16114080183 |
left |
1 |
€20,45
|
|
|
|
|
 |
Repair panel for knee pad LH side R26, R27, R50 - R69S | 4080189.7 |
16114080189.7 |
left |
1 |
€11,92
|
|
|
|
|
 |
Knee pad rubber on fuel tank, right side, R50 - R69S ►see details | 4080187 |
16114080187 |
right |
1 |
€23,41
|
|
|
|
|
 |
Repair panel for knee pad RH side R26, R27, R50 - R69S | 4080187.7 |
16114080187.7 |
right |
1 |
€11,92
|
|
|
|
11 |
|
Lenshead countersunk screw M4 x 8 - zinc plated (while supplies last) |
|
|
M4x10 |
4 |
Not available |
|
|
|
11b |
 |
Lenshead countersunk screw M3 x 10 - SSt | 9901310.3 |
07119901310.3 |
M4x10 |
1 |
€0,50
|
|
|
|
11c |
 |
Lenshead countersunk screw M4 x - SSt | 9901310.1 |
07119901310.1 |
M4x10 |
1 |
€0,50
|
|
|
|
12 |
 |
Tank badge, enamel/nickel, domed - R25/3, R26, R27, R50 - R69S original BMW ►see details | 0035322 |
51140035322 |
|
2 |
€76,45
|
|
|
|
13 |
 |
Rubber for tank badge | 6040110 |
51146040110 |
|
2 |
€1,39
|
|
|
|
14 |
|
Hex bolt M8 x 1 x 110 for fuel tank |
|
|
M8x1x110 |
1 |
Not available |
|
|
|
15 |
|
Flat washer Ø 8.4 mm |
|
|
8.4 |
2 |
Not available |
|
|
|
15 |
 |
Flat washer Ø 8.4 mm - SSt | 9931067.1 |
07119931067.1 |
8.4 |
1 |
€0,18
|
|
|
|
16 |
 |
Braided fuel hose B7 x 12, black - price / m1 (E10 proof) | 9988819 |
07119988819 |
B7x11 |
1 |
€5,81
|
|
|
|
x |
|
Braided fuel hose B7 x 12, black - price / m1 (E10 proof) | 9988819 |
07119988819 |
|
1 |
€5,81
|
|
|
|
x |
|
Braided fuel hose B7 x 12, black - price / m1 (E10 proof) | 9988819 |
07119988819 |
|
2 |
€5,81
|
|
|
|
17 |
 |
Spacer for front tank mounting | 4080136 |
16114080136 |
|
1 |
€7,02
|
|
|
|
18 |
 |
Rubber mount 'silent block', for fuel tank and muffler | 4080137 |
16114080137 |
|
2 |
€2,72
|
|
|
|
19 |
|
Flat washer Ø 8.4 mm |
|
|
8.4 |
1 |
Not available |
|
|
|
20 |
 |
Hex nut M8 x 1 SW14 - zinc plated | 9922094 |
07119922094 |
M8x1 - SW14 |
1 |
€0,61
|
|
|
|
21 |
 |
Rubber washer 10 mm for fuel tank | 4080248 |
16114080248 |
10 mm |
2 |
€3,75
|
|
|
|
22 |
 |
Mounting bracket for rear side fuel tank | 4080194 |
16114080194 |
R26 |
1 |
€22,69
|
|
|
|
23 |
 |
Rubber washer 6 mm | 4080148 |
16114080148 |
6 mm |
2 |
€2,15
|
|
|
|
24 |
|
Washer Ø 8.4 x 30 x 1 mm - Zinc plated |
|
|
Ø 8.4 x 30 |
2 |
Not available |
|
|
|
25 |
 |
Hex bolt M8 x 1 x 30 for tank mounting ►see details | 9914053 |
07119914053 |
M8x1x30 |
2 |
€1,67
|
|
|
|
26 |
 |
Gasket ring 18 x 14.5 x 1.5 for top nut on Everbest fuel cock | 4084110 |
16124084110 |
14.5x18x1.5 |
1 |
€0,69
|
|
|
|
27 |
 |
Coupling nut (top) M20 x 1 for "Everbest" Zeppelin fuel cock | 4084120.1 |
16124084120.1 |
M20x1 |
1 |
€13,79
|
|
|
|
28 |
 |
Fuel cock Frankfurter model M20x1 | 4084008.3 |
16124084008.3 |
|
1 |
€44,23
|
|
|
|
28b |
 |
Filter for fuel cock Karcoma model (inlet filter) ►see details | 4084008.F |
16124084008.F |
|
1 |
€4,66
|
|
|
|
28c |
 |
Filter for fuel cock Frankfurter model (inlet filter) ►see details | 4084008.E |
16124084008.E |
|
1 |
€5,57
|
|
|
|
|
|
Fuel cock Frankfurter model M20x1 | 4084008.3 |
16124084008.3 |
M20x1 |
1 |
€44,23
|
|
|
|
|
|
Filter for fuel cock Karcoma model (inlet filter) ►see details | 4084008.F |
16124084008.F |
|
1 |
€4,66
|
|
|
|
|
 |
Fuel cock Karcoma M20 x 1 single outlet ►see details | 1233557 |
16121233557 |
M20x1 |
1 |
€55,60
|
|
|
|
29 |
 |
Filter for Everbest Zeppelin fuel cock (discontinued) | 4084115RD |
16124084115 |
|
1 |
€0,00
|
|
|
|
30 |
 |
Hose connection for Everbest Zeppelin fuel cock (original) | 4084126RD |
16124084126 |
|
1 |
€15,55
|
|
|
|
31 |
 |
Coupling nut (lower) for "Everbest" Zeppelin fuel cock - 1 cylinder | 4084119.1 |
16124084119.1 |
|
1 |
€13,79
|
|
|
|
32 |
 |
Gasket ring 17 x 21 x 1.5 for bottom nut on Everbest fuel cock | 4084109 |
16124084109 |
|
1 |
€0,97
|
|
|
|
33 |
 |
Cork gasket ring for filter in Everbest Zeppelin fuel cock | 4084111 |
16124084111 |
|
1 |
€4,36
|
|
|
|
34 |
 |
Rubber washer 10 x 16 for toolbox lid | 9963108 |
07119963108 |
|
1 |
€0,82
|
|
|
|
35 |
|
Circlip for lock screw toolbox lid |
|
|
|
1 |
Not available |
|
|
|
35b |
 |
Retaining ring for generator cover bolt & toolbox lock screw - SSt | 4080160.2 |
16114080160.2 |
|
1 |
€1,69
|
|
|
|
36 |
 |
Mounting bracket for R26 fuel tank, U-shape | 4080196 |
16114080196 |
R26 |
1 |
€19,42
|
|
|
