1 |
|
Hex nut M3 x 0.5 |
|
|
M3x0,5 |
1 |
Not available |
|
|
|
2 |
 |
Wave washer B3 - SSt | 9933015.1 |
07119933015.1 |
B3 |
1 |
€0,11
|
|
|
|
3 |
 |
Solder lug for the contact points cable ►see details | 8566123 |
61138566123 |
4.6 mm ø |
2 |
€2,30
|
|
|
|
6 |
 |
Washer Ø 4 mm for contact points screw | 5004000 |
07075004000 |
4 mm ø |
1 |
€0,22
|
|
|
|
7 |
 |
Cylinder head screw M4 x 6 - SSt | 9919360.1 |
07119919360.1 |
M4x6 |
1 |
€0,24
|
|
|
|
7 |
|
Cylinder head screw M4 x 6 - SSt | 9919360.1 |
07119919360.1 |
M4x6 |
1 |
€0,24
|
|
|
|
8 |
 |
Insulation washer, large (set of 2 pcs) | 8004138 |
12118004138 |
large |
2 |
€4,36
|
|
|
|
9 |
 |
Washer for contact points screw | 8004140 |
12118004140 |
|
1 |
€0,28
|
|
|
|
10 |
 |
Hex bolt M3 x 9 - SSt | 9913020.1 |
07119913020.1 |
M3x9 |
1 |
€0,12
|
|
|
|
11 |
 |
Insulating washer (discontinued) | 8004136 |
12118004136 |
6 mm ø |
1 |
€1,27
|
|
|
|
|
 |
C Clip for contact points | 8030576 |
12118030576 |
|
1 |
€0,00
|
|
|
|
12 |
 |
Contact points - Noris | 9058248 |
12119058248 |
|
1 |
€19,54
|
|
|
|
14 |
 |
Spark plug NGK B8ES long reach (equiv. to Bosch W260T2 / W3CC) | 8003572 |
12128003572 |
R50, R50/2, R60, R60/2 |
2 |
€4,78
|
|
|
|
|
 |
Spark plug NGK B7ES long reach (equiv. to Bosch W260T2 / W3CC) | 8003572-T2 |
12128003572-T2 |
R69S >nr. 664 951 |
2 |
€5,38
|
|
|
|
|
|
Spark plug Bosch W 240 T1 (W4AC) short reach (discontinued) |
|
|
R50, R60 (R50S, R69, R69S) |
2 |
Not available |
|
|
|
|
|
Spark plug W260 T1 (W3AC) short reach (discontinued by Bosch) |
|
|
R50S, R69, R69S |
2 |
Not available |
|
|
|
15 |
 |
cable connection to the capacitor | 8030108 |
12318030108 |
|
2 |
€8,29
|
|
|
|
16 |
 |
Clamping screw M4.5 for original ignition coil | 8004104.7 |
12138004104.7 |
|
1 |
€2,30
|
|
|
|
x |
|
Clamping screw M4.5 for original ignition coil | 8004104.7 |
12138004104.7 |
|
2 |
€2,30
|
|
|
|
16a |
 |
Clamp for ignition coil | 8004104.A |
12138004104.A |
|
2 |
€9,50
|
|
|
|
16b |
 |
Ignition coil - high quality, made in Germany ►see details | 8004104 |
12138004104/B |
|
1 |
€240,12
|
|
|
|
16c |
|
Clamping screw M4.5 for original ignition coil | 8004104.7 |
12138004104.7 |
|
1 |
€2,30
|
|
|
|
16d |
 |
Ignition coil, after-market - Emerald Island ►see details | 8004104/H |
12138004104/H |
|
1 |
€119,49
|
|
|
|
16e |
|
Clamp for ignition coil | 8004104.A |
12138004104.A |
|
1 |
€9,50
|
|
|
|
17 |
|
Rotor - NOS (1 available) |
|
|
|
1 |
Not available |
|
|
|
18 |
|
Used part: dynamo and ignition system - complete |
|
|
<>R69 |
1 |
Not available |
|
|
|
19 |
 |
Flat washer Ø 6.4 - zinc plated | 9931043 |
07119931043 |
6.4 |
2 |
€0,07
|
|
|
|
20 |
 |
Hex nut M6 x 1.0 - zinc plated | 9922059 |
07119922059 |
M6 |
2 |
€0,12
|
|
|
|
21 |
 |
Capacitor clamp (Noris) | 8030107 |
12318030107 |
NORIS |
1 |
€6,17
|
|
|
|
x |
|
Cylinder head screw M4 x 6 - SSt | 9919360.1 |
07119919360.1 |
|
2 |
€0,24
|
|
|
|
22 |
 |
Capacitor with screw connector - 0.22μF (made in Germany) | 8030106 |
12318030106 |
|
1 |
€16,15
|
|
|
|
|
 |
Capacitor and clamp set (Noris) | 8030105 |
12318030105 |
NORIS |
1 |
€30,37
|
|
|
|
23 |
 |
Advance spring 11 mm ►see details | 8002171 |
12128002171 |
11 mm |
2 |
€4,82
|
|
|
|
|
 |
Advance spring 9 mm ►see details | 8002172 |
12128002172 |
9 mm |
2 |
€6,10
|
|
|
|
24 |
 |
Allen head hex. screw M8 x 80 | 8004100 |
12318004100 |
M8x80 |
1 |
€4,96
|
|
|
|
25 |
 |
Ignition advance unit, after-market ►see details | 8004113 |
12128004113 |
|
1 |
€207,50
|
|
|
|
x |
 |
Stop spring, inner - centrifugal governor (old) | 8004113.7 |
12128004113.7 |
old |
1 |
€15,55
|
|
|
|
x |
 |
Stop spring, outer - centrifugal governor | 8004113.3 |
12128004113.3 |
|
1 |
€8,41
|
|
|
|
x |
 |
Felt pad with spring for advance unit - Noris | 0001927 |
12310001927 |
|
1 |
€9,62
|
|
|
|
x |
 |
Washer for aluminum rivets for oil felt leaf spring (contact points) | 8030110.L |
12118030110.L |
|
2 |
€0,12
|
|
|
|
x |
 |
Alu rivet - round head 2 x 5, for oil felt on leaf spring (contact points) | 8030110.M |
12118030110.M |
|
1 |
€0,12
|
|
|
|
x |
 |
Alu rivet - round head 2 x 3, for oil felt leaf spring (contact points) | 8030110.N |
12118030110.N |
|
2 |
€0,12
|
|
|
|
28 |
 |
Spring ignition timing R68, R69 | 8004146 |
12128004146 |
R69 |
1 |
€12,69
|
|
|
|
29 |
 |
Fitting for advance cable R68, R69 - temporarily unavailable | 8004148 |
12128004148 |
R69 |
1 |
€8,89
|
|
|
|
30 |
 |
End sleeve for ignition cable | 8036165 |
12128036165 |
|
2 |
€0,30
|
|
|
|
31 |
 |
Rubber grommet sparkplug wire | 8036150 |
12128036150 |
|
2 |
€1,71
|
|
|
|
32 |
 |
Spark plug wire BERU, silicone - copper core cable - 1 meter | 8036124 |
12128036124 |
|
2 |
€8,35
|
|
|
|
33 |
 |
Rubber cover for spark plug cap and cable (BERU) | 8036160 |
12128036160 |
for Bakelite and Beru caps |
2 |
€1,56
|
|
|
|
|
 |
Spark plug cap Bosch - NOS, 1 KΩ resistor | 8036514 |
12128036514 |
for Bosch cap |
2 |
€16,27
|
|
|
|
34 |
 |
Spark plug cap BERU - 1 KΩ resistor ►see details | 8036157 |
12128036157 |
|
2 |
€10,95
|
|
|
|
36,27 |
 |
Spark plug cap - original BMW, with logo - 0 KΩ | 5590014 |
12125590014 |
|
2 |
€30,25
|
|
|
|
|
 |
C Clip for contact points 3.2 | 01866 |
07119932815 |
|
1 |
€1,03
|
|
|
|
|
 |
Speedi Sleeve 25 mm for magneto rotor ►see details | 99098 |
|
R50 - R69S <>R69 |
1 |
€41,02
|
|
|
|
|
 |
Spark plug cap - Noris, with logo - 0 KΩ | 8036156 |
12128036156 |
|
2 |
€29,34
|
|
|
|
|
 |
Spark plug cap with BMW logo - Bakelite - 0 KΩ ►see details | 8036104 |
12128036104 |
|
2 |
€18,88
|
|
|
